8000m Series
- 39 -
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modifica-
tion Type
F5.04 Reserved
24: Simple PLC pause
25: PID pause
26: Swing frequency pause
(maintain at current frequency)
27: Reset after swing frequency
pause (reset to central
frequency)
28: Counter reset
29:Reserved
30:Acceleration/deceleration
prohibited
31:Counter triggering
32:Clear UP/DOWN setting
temporarily
33: Reserved
34: Length counting input
35: Length counting clear up
36: Command source switch
37: Terminal input delay output
38: Reserved
F5.05 Reserved 0 ●
F5.06 ~
F5.08
Reserved
F5.09
VDI Virtual Input
terminal
function(Note:
VDI input is VDO
output, without
limit by On/off
filter times F5.10)
0 ●
F5.10 On/off filter times 1~10 5 ○
F5.11
Terminal control
mode
0:2-wire control mode 1
2:2-wire control mode 2
3:3-wire control mode 1
4:3-wire control mode 2
0 ●
F5.12
Frequency
changing rate
through UP/
DOWN terminal
adjusting
0.01~50.00Hz/s 0.01Hz/s 0.50Hz/s ○
F5.13 AVI lower limit 0.00V~10.00V 0.01V 0.00V ○
