SAJ 8000m Series User Manual

8000m Series
- 40 -
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modifica-
tion Type
F5.14
Setting value
corresponding to
AVI lower limit
-100.0%~100.0% 0.10% 0.00% ○
F5.15 AVI upper limit 0.00V~10.00V 0.01V 10.00V ○
F5.16
Setting value
corresponding to
AVI upper limit
-100.0%~100.0% 0.10% 100.00% ○
F5.17
AVI input filter
time
0.00s~10.00s 0.01s 0.10s ○
F5.18~F
5.22
Reserved
F5.23 M1 On delay 0.0s
～
6000.0s 0.1s 0.0s ○
F5.24 M1 Off delay 0.0s
～
6000.0s 0.1s 0.0s ○
F5.25 M2 On delay 0.0s
～
6000.0s 0.1s 0.0s ○
F5.26 M2 Off delay 0.0s
～
6000.0s 0.1s 0.0s ○
F5.27 ~
F5.32
Reserved
F6 Group: Output Terminals Parameters
F6.00
MO1 output
selection
0: No output
1: Motor forward running
2: Motor reverse running
3: Fault output
4: Frequency detecting level
FDT output
5: Frequency reached
6: Running at zero speed
7: Upper limit frequency
reached
1 ○
F6.01 Reserved
