SAJ 8000m Series

8000m Series
- 47 -
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modifica-
tion Type
F9.00 PID setting source
0:Keypad (F9.01)
1:Analog terminal AVI
2:Reserved
3:Communication interface
4:Muli-function digital input
terminals
0 ○
F9.01 PID preset value 0.0%~100.0% 0.10% 0.00% ●
F9.02
PID feedback
selection
0:Analog terminal AVI
1:Reserved
2:Reserved
3:Communication interface
0 ○
F9.03
PID output
characteristic
0: Positive
1: Negative
0 ○
F9.04
Proportional gain
(Kp)
0.0~100.0 0.1 0.1 ○
F9.05 Integral time (Ti) 0.01~10.00s 0.01s 0.10s ○
F9.06
Differential time
(Td)
0.00~10.00s 0.01s 0.00s ○
F9.07
Sampling period
(T)
0.01~100.0s 0.01s 0.10s ○
F9.08
PID control
deviation limit
0.0~100.0% 0.10% 0.00% ○
F9.09
Feedback loss
detecting time
0.0~100.0% 0.10% 0.00% ○
F9.10
Feedback lost
detecting time
0.0~3600.0s 0.1s 1.0s ○
F9.11
PID sleep function
option
0: PID normal working
1: PID sleep
0 ○
F9.12
PID sleep detecting
delay time
0.0~3600.0s 0.1s 3.0s ○
