8000m Series
- 58 -
Select the input channel of master frequency of the VFD. Altogether 8 master
frequency channels are available:
0: digital setting of the panel
The initial value is the value of F0.08 “keypad setting frequency”.
The settings of frequency value of the VFD can be adjusted through ▲and ▼ key
and the multi-function digital input terminal UP/DOWN terminal.
1: settings by a potentiometer of the panel
2: AVI
Option of AVI is that the frequency is determined by one of the analog input
terminals. A standard VFD unit has 2 analog input terminals, among them AVI is
input by voltage 0～10V；by using jump line selection, ACI can be chose in the way
of 0～10V voltage and 0/4～20mA current.
3: Reserved
4: Reserved
5: Reserved
6: Multi-step speed terminals
F0.03
Settings of master frequency source X Factory Setting 1
Setting Options
0 Digital setting Up/down key
1 Potentiometer of panel
2 AVI terminal
3 Reserved
4 Reserved
5 Reserved
6 Multi-step speed terminals
7 Simple PLC
8 PID
9 Communication interface
