SAJ R5 Series User Manual

R5 Series
- 9 -
3.2 Specification for Product Model
R5 – XK – T2 –AUS
① ② ③ ④
① R5 represents for product name.
② XK represents rated power XkW of inverter, for example 4K means 4kW.
③ T means three phase; 2 represents the inverter has the function of dual MPPT.
④AUS For Australia
3.3 Overview of products
The dimensions of R5 series products is shown in Figure 3.2.
Figure 3.2 Dimensions of R5-3K/4K/5K/6K/8K/9K/10K-T2-AUS
Figure 3.3 Dimensions of R5-15/17K/20K-T2-AUS

SAJ R5 Series Specifications

General

MPPT	Yes
Display	LCD
Number of MPP Trackers	2
Cooling Method	Natural convection
Type	Grid-tied Inverter
Communication	WiFi, Ethernet, RS485
Operating Temperature Range	-25°C ~ +60°C
Output Voltage Range	230V
