SAJ R5 Series User Manual

R5 Series
- 10 -
3.4 Datasheet
R5-3K/4K/5K/6K-T2-AUS
Type
R5-3K-T2-AUS
R5-4K-T2-AUS
R5-5K-T2-AUS
R5-6K-T2-AUS
Input (DC)
Max. PV Array Power [Wp]@STC
4500
6000
7500
9000
Max. DC Voltage[V]
600
MPPT Voltage range [V]
160-550
Nominal DC Voltage[V]
480
Start Voltage[V]
180
Min. DC Voltage[V]
150
Max. DC Input Current [A]
12.5/12.5
Max. DC Short Current [A]
15/15
Number of DC Connection Sets per
MPPT
1/1
Number of MPPT
2
Output (AC)
Rated AC Power[W]
3000
4000
5000
6000
Max. AC Power[VA]
3300
4400
5500
6600
Rated AC Current [A]
4.4
5.8
7.3
8.7
Max. AC Current [A]
5.0
6.7
8.4
10.0
Current Inrush [A]
50
Feedback Current [A]
0.1
Max. AC Fault Current [A]
24.5
24.5
24.5
24.5
Max. AC Over Current Protection [A]
28.4
28.4
28.4
28.4
Nominal AC Voltage/ Range[V]
220/380,230/400,240/415;180-280/312-485
Grid Frequency/ Range[Hz]
50,60/45-55,55-65
Power Factor[cos φ]
0.8 leading~0.8 lagging
Total Harmonic Distortion[THDi]
< 2%
Feed-in
3L+N+PE
Efficiency
Max. Efficiency
98.0%
98.3%
Euro Efficiency
97.6%
98.0%
MPPT Accuracy
>99.5%
Protection
Internal Over-voltage Protection
Integrated
DC Insulation Monitoring
Integrated

SAJ R5 Series Specifications

General

MPPT	Yes
Display	LCD
Number of MPP Trackers	2
Cooling Method	Natural convection
Type	Grid-tied Inverter
Communication	WiFi, Ethernet, RS485
Operating Temperature Range	-25°C ~ +60°C
Output Voltage Range	230V
