SAJ R5 Series User Manual

R5 Series
- 7 -
2.2 Explanations of Symbols
Symbol
Description
Dangerous electrical voltage
This device is directly connected to public grid, thus all work to the inverter
shall only be carried out by qualified personnel.
Danger to life due to high electrical voltage!
There might be residual currents in inverter because of large capacitors. Wait
for 5 minutes before you remove the front lid.
Notice, danger!
This is directly connected with electricity generators and public grid.
Danger of hot surface
The components inside the inverter will release a lot of heat during operation.
Do not touch metal plate housing during operating.
An error has occurred
Please go to Chapter 9 “Troubleshooting” to remedy the error.
This device shall not be disposed of in residential waste
Please go to Chapter 8 “Recycling and Disposal” for proper treatments.
Without Transformer
This inverter does not use transformer for the isolation function.
CE Mark
Equipment with the CE mark fulfills the basic requirements of the Guideline
Governing Low-Voltage and Electro-magnetic Compatibility.
CQC Mark
The inverter complies with the safety instructions from China's Quality Center.

SAJ R5 Series Specifications

General

MPPT	Yes
Display	LCD
Number of MPP Trackers	2
Cooling Method	Natural convection
Type	Grid-tied Inverter
Communication	WiFi, Ethernet, RS485
Operating Temperature Range	-25°C ~ +60°C
Output Voltage Range	230V
