R5 Series
- 25 -
Code
Name
A
DC Switch(Optional)
B
Decompression Valves
C
DC Input
D
DRM
E
RS232 Communication (GPRS/ Wi-Fi /4G)
F
Ground Connection
G
RS485 Communication
H
AC Output
Table 5.1 Specifications for interface
Figure 5.3 Electrical interface of R5-15K/17K/20K-T2-AUS
