SAJ VM1000B

VM1000B
- 29 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
F5.22
AI1 filter time
0.00s ～ 10.00s
0.10s
○
0516
F5.23
AI2 minimum input
0.00V ～ F5.25
0.00V
○
0517
F5.24
Percentage rate of AI2
minimum input
-100.0% ～ +100.0%
0.00%
○
0518
F5.25
AI2 maximum input
F5.23 ～ +10.00V
10.00V
○
0519
F5.26
Percentage rate of AI2
maximum input
-100.0% ～ +100.0%
100.00%
○
051A
F5.27
AI2 filter time
0.00s ～ 10.00s
0.10s
○
051B
F5.28
Reserved
-
-
○
051C
F5.29
Reserved
-
-
○
051D
F5.30
Reserved
-
-
○
051E
F5.31
Reserved
-
-
○
051F
F5.32
Reserved
-
-
○
0520
F5.33
DI1 enable delay time
0.0s ～ 3600.0s
0.0s
○
0521
F5.34
DI2 enable delay time
0.0s ～ 3600.0s
0.0s
○
0522
F5.35
DI1 disabled delay time
0.0s ～ 3600.0s
0.0s
○
0523
F5.36
DI2 disabled delay time
0.0s ～ 3600.0s
0.0s
○
0524
F5.37
DI valid mode selection 1
0: High level
1: Low level
Single digit: DI1
Ten’s digit: DI2
Hundred’s digit: DI3
Thousand’s digit: DI4
Ten Thousand’s digit: DI5
0
●
0525
F5.38
DI valid mode selection 2
0: High level
1: Low level
Single digit: DI6
Ten’s digit: Reserved
Hundred’s digit: Reserved
Thousand’s digit: Reserved
Ten Thousand’s digit: Reserved
0
●
0526
F5.39
AI1 zero drift coefficient
0～50.00
0
○
0527
F5.40
AI2 zero drift coefficient
0～50.00
0
○
0528
F6 Group: output terminal
F6.00
FM terminal out mode
0: Reserved
1: Open-collector output (FMR)
1
○
0600
F6.01
FMR function
0: No output
1: AC Drive operation
0
○
0601
F6.02
Relay 1 function
2
○
0602
