VM1000B
- 33 -
Function
Code
Parameter Name
Setting Range
Default
Property
Address
(HEX)
Ten’s digit: output method
0: False value output
1: Real value output
F6.35
User defined output dead
zone 2
0 65535
0
0623
F6.36
User-defined 2 output
comparison value 1
0 65535
0
0624
F6.37
User-defined 2 output
comparison value 2
0 65535
0
0625
F6.38
The setting time of timer
0.00s100.00s
10
0626
F7 Group: keypad and display
F7.00
LCD keypad parameter
copy
0: No operation
1: The native function parameters are
uploaded
to the LCD keypad
2: LCD keypad function parameters
are
downloaded to the machine
0
0700
F7.01
MF.K key function
selection
0: MF.K disabled
1: Switchover between keypad control and
remote command control(terminal or
communication)
2: Switchover between forward rotation and
reverse rotation
3: Forward JOG
4: Reverse JOG
5: Menu mode switching
0
0701
F7.02
STOP/RESET key
function
0: STOP/RESET key enable only in keypad
control
1: STOP/RESET key enable in any operation
mode
1
0702
F7.03
LED display running
parameters 1
0000 FFFF
Bit00: Running frequency (Hz)
Bit01: Setting frequency (Hz)
Bit02: DC bus voltage (V)
Bit03: Output voltage (V)
Bit04: Output current (A)
Bit05: Output power (kW)
Bit06: Output torque (%)
Bit07: DI input status
Bit08: DO output status
Bit09: AI1 power (V)
Bit10: AI2 power (V)
Bit11: Reserved
Bit12: Count value
Bit13: Length value
Bit14: Load speed display
17
0703
