105
Acc/Dec
time
selection
terminal 2
Acc/Dec
time
selection
terminal 1
Acc/Dec time
selection
OFF OFF
Acc time 1/Dec
time 1
OFF ON
Acc time 2/Dec
time 2
ON OFF
Acc time 3/Dec
time 3
ON ON
Acc time 4/Dec
time 4
Run
command
channel
selection
terminal 2
Run
command
channel
selection
terminal 1
Run command
channel
OFF OFF
Determined by
function code
P0.06
OFF ON 0: keypad
ON OFF 1: terminal
ON ON
2: communication
21: run command channel 1
22: run command channel 2
By selecting the ON/OFF combination of
these function terminals, there would be
3 kinds of run command channels and 4
kinds of methods at most, as showed in
the following table.
23: Acc/Dec prohibit
When this terminal is valid, VFD will
maintain current frequency without
influence of external signal (except stop
command).
24: VFD operating prohibiting
If this function is enabled, the drive that is
operating will coast to stop and the drive
4.2 Detailed Function Description
ready to run will be prohibited to start.
This function is mainly used as safety
protection.
25: switch operating command to keypad
When this terminal function is enabled, the
operating command is switched to keypad
control from present channel forcibly. If
the terminal is disconnected, the previous
operating command channel will be
enabled.
26: switch operating command to terminal
When this terminal function is enabled,
the operating command is switched to
terminal control from present channel
forcibly. If the terminal is disconnected,
the previous operating command channel
will be enabled.
27: switch operating command to communication
When this terminal function is enabled,
the operating command is switched to
communication control from present
channel forcibly. If the terminal is
disconnected, the previous operating
command channel will be enabled.
28: clear the setting of auxiliary frequency
This function is only valid for digital
auxiliary frequency (F0.08=0, 1, 2) to clear
it to zero, so that the reference frequency
is determined solely bay main reference.
29: switch from frequency source A to K*B
When this terminal function is enabled, if
F0.09 (frequency combinational algorithm)
is set as 6, the frequency setting channel is
switched to frequency source B, and back
to A when it is disabled.
30: switch from frequency source A to A+K*B
When this terminal function is enabled, if
