148
Address 01H
Function 06H
Starting data address
20H
00H
Data(2Byte)
00H
01H
CRC CHK Low 43H
CRC CHK High CAH
4) 06H write single parameter
Inquiry information frame format (send frame):
Analysis of this segment data:
01H is the address of the driver
06H write function code
2000H is the address of control command
0001H is forward command
43A1H is 16 bits of CRC check code
Communication Protocol
Name Frame format
Read fault code E-19 (address E000H and
1E00H interchangeable, refer to the fault code
table)
Send frame: 01H 03H E000H 0001H B3CAH
Return frame: 01H 03H 02H 0013H F989H
Send frame: 01H 03H 1E00H 0001H 8222H
Return frame: 01H 03H 02H 0013H F989H
Read pre-alarm code A-18 (address E001H and
1E01 interchangeable, refer to the pre-alarm
code table)
Send frame: 01H 03H E001H 0001H E20AH
Return frame: 01H 03H 02H 0012H 3849H
Send frame: 01H 03H 1E01H 0001H D3E2H
Return frame: 01H 03H 02H 0012H 3849H
Example:
