5) 10H write multiple parameters continuously
Inquiry information frame format (send frame):
Address 01H
Function 10H
Starting data address
01H
00H
Number of Data(Byte)
00H
02H
DataNum*2 04H
Data1(2Byte)
00H
01H
Data2(2Byte)
00H
02H
CRC CHK High 2EH
CRC CHK Low 3EH
Analysis of this segment data:
01H is the address of the driver
10H write function code
0100H start address, equivalent to F1.00 of control panel
0002H amout of registers
04H bytes sum (2*register amout)
0001H data of F1.00
0002H data of F1.01
2E3EH 16 bits of CRC check code
