026
D Group - Monitoring Parameter Group and Fault Record
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
d-15 PID Feedback (V) 0.00 ～ 10.00V 0.01V 0.00 ◆
d-16 Analog Input AI1(V/mA) 0.00 ～ 10.00V/20mA 0.01V 0.00 ◆
d-17 Analog Input AI2(V) 0.00 ～ 10.00V 0.01V 0.00 ◆
d-18
Impulse Frequency
Imput (KHz)
0.00 ～ 50.00KHz 0.01KHz 0.00 ◆
d-19 Analog Output AO1(V/mA) 0.00 ～ 10.00V/20mA 0.01V 0.00 ◆
d-20 Analog Output AO2(V) 0.00 ～ 10.00V 0.01V 0.00 ◆
d-21 Input Terminal Status
0 ～ FFH
Note: the sequence from high to
low order digit in binary system
X8/X7/X6/X5/X4/X3/X2/X1
1 0 ◆
d-22 Output Terminal Status
0～FH
Note: the sequence from high to
low order digit in binary system
R2/R1/Y2/Y1
1 0 ◆
d-23 VFD Running Status
O ～ FFFFH
BIT0: run/stop
BIT1: reverse/forward
BIT2: zero-speed running
BIT3: reserved
BIT4: accelerating
BIT5: decelerating
BIT6: constant speed running
BIT7: pre-excitation
BIT8: tuning of VFD parameter
BIT9: overcurrent limit
BIT10: overvoltage limit
BIT11: amplitude limiting of
torque
BIT12: amplitude limiting of
speed
BIT13: speed control
BIT14: torque control
BIT15: reserved
1 0 ◆
4.0 Monitoring Parameter Group and Fault Record
