054
4.1 Function Code
F7 Group - Digital Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F7.25 FDT1 level
0.00Hz ～【F0.16】upper limit
freq.
0.01Hz 50.00 ○
F7.26 FDT1 lag 0.0 ～ 100.0％ *【F7.25】 0.1% 2.0% ○
F7.27
FDT2 detection
method
0: speed set value
1: speed detected value
1 0 ○
F7.28 FDT2 level
0.00Hz ～【F0.16】upper limit freq. 0.01Hz 25.00 ○
F7.29 FDT2 lag 0.0 ～ 100.0％ *【F7.28】 0.1% 4.0% ○
F7.30
Counting value arrival
processing
0: stop counting, stop output
1: stop counting, resume output
2: cycle count, stop output
3: cycle count, resume output
1 3 ×
F7.31
Counting start
condition
0: always count since power on
1: count in operation status, stop
counting in stop status
1 1 ×
F7.32 Counter reset value 【F7.33】～ 65535 1 0 ○
F7.33
Counter detection
value
0 ～【F7.32】 1 0 ○
F7.34 time out processing
0: stop timing, stop output
1: stop timing, resume output
2: cycle timing, stop output
3: cycle timing, resume output
1 3 ×
F7.35 Timing start condition
0: timing starts since power on
1: timing starts in operation status,
and stops in stop status
1 1 ×
F7.36 Timing setting 0 ～ 65535s 1s 0 ○
F7.37 Y1 turn o󽗈 delay time 0.0 ～ 100.0s 0.1s 0.0 ×
F7.38 Y2 turn o󽗈 delay time 0.0 ～ 100.0s 0.1s 0.0 ×
F7.39 R1 turn o󽗈 delay time 0.0 ～ 100.0s 0.1s 0.0 ×
F7.40 R2 turn o󽗈 delay time 0.0 ～ 100.0s 0.1s 0.0 ×
