4.1 Function Code
F7 Group - Digital Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modication
F7.21
Programmable
relay R2 output
26: dynamic braking action
27: DC braking action
28: ux braking action
29: torque limiting
30: over torque signal
31: auxiliary motor 1
32: auxiliary motor 2
33: accumulated operation time out
34 ～ 49: segment of MS or simple PLC
operation
50: running indication signal
51: temperature arrival indication
52: indicate when VFD stops or runs at
zero speed
53: reserved
54: reserved
55: communication setting
56: drive ready 2
57: The output indication signal is
output when AI1 input over limit.
58 ～ 99: reserved
1 0 ×
F7.22
Logic setting of
output terminal
(Y1 ～ Y2)
0～3H
0: positive logic, i.e. terminal Yi is
enabled when it connects with
common terminal, and disabled if
disconnected.
1: negative logic, i.e. terminal Yi
is disabled when it connects with
common terminal, and enabled if
disconnected.
1 0 ×
F7.23
Freq. arrival
detectionrange
(FAR)
0.0 ～ 100.0％ *【F0.15】max. freq. 0.1% 10.0% ○
F7.24
FDT1 detection
method
0: speed set value
1: speed detected value
1 0 ○
