052
4.1 Function Code
F7 Group - Digital Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F7.18
Open collector
output
terminal Y1
0: no output
1: VFD forward running
2: VFD reverse running
3: fault output
4: freq./speed level detection signal
(FDT1)
5: freq./speed level detection signal
(FDT2)
6: freq./speed arrival signal (FAR)
7: VFD zero-speed running
8: upper limit arrival of output freq.
9: lower limit arrival of output freq.
10: lower limit arrival of preset freq.
during running
11: pre-alarm signal of overload
12: counter detection signal output
13: counter detection reset signal
output
14: driver ready 1
15: one cycle 󽗉nished of programmable
MS running
16: stage 󽗉nished of pogrammable MS
running
17: upper and lower limit of traverse freq.
18: current limiting action
19: stall over voltage
20: low voltage lock-up
21: dormancy state
22: VFD alarm signal (PID disconnection,
RS485 communication failure, panel
communication failure, EEPROM
read-write failure, encoder
disconnection, etc.)
23: AI1>AI2
24: preset length arrival
25: preset operation time out
1 0 ×
F7.19
Open collector
output
terminal Y2
1 0 ×
F7.20
Programmable
relay R1
output
1 3 ×
