Sako SKI600 - Page 57

051
4.1 Function Code
F7 Group - Digital Input and Output Parameters
Function
Code
Name Set Range
Minimum
Unit
Factory
Default
Modi󽗉cation
F7.07 reserved — — 0 ◆
F7.08
Digital 󽗉ltering
times
1 ～ 10 1: 2MS unit of scanning
time
1 5 ○
F7.09
Terminal function
detection when
power on
0: terminal operation command
invalid when power on
1: terminal operation command
valid when power on
1 0 ○
F7.10
E󽗈ective logic
setting of input
terminal (X1 ～ X8)
0 ～ FFH
0 is positive logic, i.e. terminal Xi
is enabled when it connects with
common terminal and disabled
if disconnected.
1 is negative logic, i.e. terminal
Xi is disabled when it connects
with common terminal and
enabled when disconnected.
1 00 ×
F7.11
FWD/REV terminal
control mode
0: two-wire control mode 1
1: two-wire control mode 2
2: three-wire control mode 2
3: three-wire control mode 1
1 0 ×
F7.12
UP/DOWN
terminal frequency
modifying rate
0.01 ～ 50.00Hz/s 0.01Hz/s 1.00 ○
F7.13 reserved — — 0 ◆
F7.14
Y1 output delay
time
0.0 ～ 100.0s 0.1s 0.0 ×
F7.15
Y2 output delay
time
0.0 ～ 100.0s 0.1s 0.0 ×
F7.16
R1 output delay
time
0.0 ～ 100.0s 0.1s 0.0 ×
F7.17
R2 output delay
time (reserved)
0.0 ～ 100.0s 0.1s 0.0 ×
