Saleae Logic 8 User Manual

Page 10 of 69
true high-speed USB 2.0 isolator on the market. All other USB 2.0 isolators are only full speed and low
speed, which is insufficient for our products to operate.
Warranty Coverage
Saleae products are covered by a 3-year warranty, regardless of where you purchased the product. For
more information, see: 180-Day Return Policy and 3-Year Warranty
If you believe your Logic hardware is broken, please follow the troubleshooting steps in the article
here: Saleae Warranty & RMA Testing Procedure
Afterwards, if the device continues to fail, write a message to us with the detailed results of the
troubleshooting steps, as well as any relevant information that is requested in that article.

Saleae Logic 8 Specifications

General

Channels	8
Digital Sample Rate	100 MS/s
Analog Sample Rate	10 MS/s
Analog Bandwidth	5 MHz
Analog Resolution	12 bits
Input Impedance	1 MΩ || 10 pF
Connectivity	USB 2.0
Operating System Compatibility	Windows, macOS, Linux
Power Supply	USB Powered
Logic Level	1.2V to 5.5V
Digital Voltage Range	0V to 5.5V
Supported Protocols	I2C, SPI, UART, CAN
