24
The RT510TX thermostat requires no special maintenance. Periodically, the outer casing can be wiped clean using a dry cloth (please DO NOT use solvents,
polishes, detergents or abrasive cleaners, as these can damage the thermostat). There are no user serviceable parts within the unit; any servicing or
repairs could only be carried out by Salus Controls or their appointed agents.
11. Cleaning and Maintenance
Transmitter’s power supply 2 x AA batteries
Receiver’s power supply 230V AC 50 Hz
Rating max 16 (5) A
Output signal NO/COM relay
Temperature range 5 - 35°C
Display temperature accuracy 0.1°C or 0.5°C
Control algorithm TPI or Hysteresis: ±0.25°C
Communication Wireless, 868Mhz
Dimension [mm]
transmitter: 120 x 96 x 27
receiver: 96 x 96 x 27
12. Technical Informations
96 mm 27 mm
96 mm 96 mm
120 mm 27 mm
96 mm 96 mm
