Sam4s ELLIX50 - WLAN Interface DIP Switch Set; Serial+Ethernet Interface DIP Switch Set

OPERATOR’S Manual
15
CHAPTER 1
1.7.2. WLAN lnterface DIP Switch Set
•
DIP Switch Set 1 Functions
S/W FUNCTION ON OFF DEFAULT
1 WLAN Disable Enable OFF
2 No - - -
3 No - - -
4 No - - -
5 No - - -
6 No - - -
7 No - - -
8 USB Mode VCOM USB OFF
•
DIP Switch Set 2 Functions
※
Dip Switch 2 Functions are the same as the series interface.
1.7.3. Serial+Ethernet Interface DIP Switch Set
•
DIP Switch Set 1 Functions
※
Dip Switch 1 Functions are the same as the series interface.
•
DIP Switch Set 2 Functions
S/W FUNCTION ON OFF DEFAULT
1 Emulation STAR EPSON OFF
2 * Kitchen Bell Enable Disable OFF
3 Auto Cutter Disable Enable OFF
4 Self-Test Mode Hex Dump Self-Test Mode OFF
5
Select Print
Density
*
Refer to the page 14 Table
OFF
6 OFF
7 Download Mode Memory Stick Interface OFF
8
Communication
Mode
RS-232 ETHERNET OFF
※
Kitchen Bell is option.
