SAMES KREMLIN 20F50 - Page 146

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
146
 Grease the rod of the control fork (13) as well as the
rod of the reversing block (9a/9b).
 Place the interface plate (6).
 Screw in the screw (7) with a 13 mm open-end wrench
and screw (8) with a 6 mm Allen wrench.
Tools needed
23
9a/9b
13
7
6
8
6
13
