SAMES KREMLIN 20F50 - Page 66

20/11/2020 582156110-EN-indC-Pump-20F50 pH.docx
66
 Place the suction bearing assembly (6), bellows (8)
and skirt (10) on the intermediate piston (11).
 Tighten the skirt (10) by holding it with a 36 mm open-
end wrench and tightening the intermediate
piston(11) with an 11 mm open-end wrench.
Tools needed
10
8
6
10
10
11
36
