5.11 CHARGING LITHIUM ION BATTERIES
!
CAUTION!
The Battery Management System (BMS) that comes with the Lithium Ion Battery being used may need to have
control over charging and discharging of the battery. For this, any of Pins 1/2/3/4 and any of Pins 5/6/7/8 of the
Temperature Sensor Jack (6, Fig 2.1; Pinout at Fig 3.13) may be used to feed potential free contact closing signal
from the BMS to “Stop Charging” or “Stop Inverting. See Section 5.11.2 below for details.
!
ATTENTION!
Le système de gestion de la batterie (BMS) qui vient avec la batterie au lithium-ion utilisé peut avoir besoin
d'avoir le contrôle de charge et décharge de la batterie. Pour cela, n’importe lequel des broches 1/2/3/4
et 5/6/7/8 de la prise de capteur de température (6, Fig. 2.1; Pinout à la Fig. 3.13) peut être utilisé pour
l'alimentation contact libre de signal de fermeture de la BMS à "arrêter la charge" ou "arrêter d'inverser".
Se reporter à la Section 5.11.2 pour plus de détails.
5.11.1 Charging Proles for Lithium Batteries
Programming parameter “CHARGING PROFILE” is used to select up to 5 programming options for 2/3-Stage charging
proles for Lithium Ion Batteries. Details are given in Table below:
Srl. No. Table 5.2 Srl. No. of Table 5.3 Option under Parameter "CHARGING" Prole (Section
4.4.4.2.21 of EVO-RC Remote Control Manual attached
at Appendix A
2 — "1 = 3-Stage Type 1"
3 — "2 = 3-Stage Type 2"
— 1 "3 = 2-Stage Type 1"
— 2 "4 = 2-Stage Type 2"
— 3 "5 = 2-Stage Type 3"
i
INFO
Charging of Lithium Ion Batteries is not affected by temperature and hence, Battery Temperature Sensor Model
EVO-BCTS [Fig 2.5(a)] is not required to be used
5.11.2 Stop Charging and Stop Inverting Protections when Charging Lithium Batteries
For background information, refer to Section 4.4.2.22.2 in the EVO-RC-PLUS Remote Control Manual. For protection
against over-voltage / over-temperature / over-discharge, Lithium Ion Battery Management Systems (BMS) will normally
