120 | SAMLEX AMERICA INC.
ATTENTION!
Lorsque « Switch Type » de ON/OFF contrôle décrit ci-dessus est sélectionnée, le bouton on/
off sur le panneau avant de l’unité (12, Fig 2.1) ne devraient pas servir à allumer ou éteindre
l’appareil. La façade, bouton poussoir On/Off suivra désormais la logique de contrôle ci-dessus
« Switch Type » dans lequel l’appareil demeurera allumé aussi longtemps que la touche est
maintenue enfoncée et s’éteint après 2 secondes après que qu’il est libéré.
6.3 OPERATIONAL INFORMATION THROUGH LEDS AND BUZZER
Table 6.1 shows the operational states of the unit indicated by the following LEDs on the front panel of the unit and
Buzzer:
o Blue LED marked “ON” (12, Fig 2.1)
o Red LED marked “Fault” (13, Fig 2.1)
Optional Remote Control Model EVO-RC-PLUS will be required for more detailed messaging that is available through
its LCD display and LEDs. This remote will also be required for programming of various parameters to suit specic
requirements.
TABLE 6.1 FRONT PANEL LED AND BUZZER INDICATIONS
Status
Blue LED
marked “ON”
(12, Fig 2.1)
Red LED
marked “Fault”
(13, Fig 2.1)
Buzzer
(See NOTE 1 Below)
Seen during Power-On Sequence
(Refer to Section 6.1.1)
Blink 3 times & then off Off Off
Seen during Power-Off Sequence
(Refer to Section 6.1.2)
On On Off
Normal charging Blink once in 1 sec interval Off Off
Equalization charging Blink twice in 1 sec
interval
Off Off
Inverting (Discharging) On Off Beep once in 3 sec
interval
Low battery alarm On Blink once in 1 sec
interval
Beep once in 1 sec
interval
Power saving Blink once in 3 sec interval Off Off
Standby Blink once in 5 sec interval Off Off
Fault Off On On
NOTE 1:
The buzzer can be switched on or off through programming parameter "BUZZER"[Refer to Section 4.8.2.7 of EVO-
RC-PLUS Manual. The default setting is "1 = On"].
SECTION 6 | Operation, Protections and Troubleshooting
