6.4 OPTIONAL REMOTE CONTROL EVO-RC-PLUS FOR PROGRAMMING OF MODES OF
OPERATION AND PARAMETERS
Optional Remote Control Model EVO-RC-PLUS [Fig 2.4(a)] will be required for more advanced control and monitoring.
Please see separate Owner’s Manual for EVO-RC-PLUS. The Remote Control comes with 10M / 33 ft., RJ-45 Data Cable.
The Remote plugs into RJ-45 Jack on the front panel of the unit (7, Fig 2.1). It has provision for Data Logging using SD
Card of up to 16 GB (FAT16 / FAT32). It also has its own Real Time Clock and Super Capacitor Type of Battery.
Detailed messaging is available through its LCD display and LEDs. This remote will also be required for programming of
various parameters to suit specic requirements. Each programmable parameter has a Default Value. This unit has been
shipped with the various parameters set at the Default Values.
6.4.1 Programmable & Default Values of Programming Parameters
Programmable and Default values are shown in Tables 6.2 to 6.6:
TABLE 6.2 PROGRAMMABLE AND DEFAULT PARAMETERS: PARAMETER GROUP NO.1 "CHARGING CURVE"
Parameter
Programming Range
(Programming requires optional
Remote Control Model EVO-RC-PLUS)
Default
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
“BULK CURRENT” (See NOTE 1)
(Bulk Charge Current “Io”)
0-60A 0-40A 20A
“ABSORP VOLTAGE”
(Absorption Voltage)
12.00V - 16.00V 24.00V - 32.00V 14.40V 28.80V
“EQUALIZE VOLTAGE”
(Equalization Voltage)
14.00V - 16.50V 28.00V - 33.00V 14.40V 28.80V
“FLOAT VOLTAGE"
(Float Voltage)
12.00V - 15.00V 24.00V - 30.00V 13.50V 27.00V
“COMPENSATE”
(Temperature Compensation)
3mV to 5mV /C/Cell 4mV /C/Cell
“BATT OVER VOLT”
(Battery Over Voltage Shutdown)
14.00V - 17.00V 28.00V - 35.00V 16.00V 32.00V
“RESET VOLTAGE”
(Reset voltage for "BATT LOW
VOLTAGE" condition)
12.00V - 17.00V 28.00V - 35.00V 14.00V 28.00V
“LOW VOLT ALARM”
(Battery Low Voltage Alarm)
9.50V to 13.50V 19.00V to 27.00V 11.00V 22.00V
“BATT LOW VOLTAGE”
(Battery Low Voltage Shutdown)
>9.00V to 13.00V >18.00V to 26.00V 10.50V 21.00V
