122 | SAMLEX AMERICA INC.
SECTION 6 | Operation, Protections and Troubleshooting
“LV DETECT TIME”
(Time to qualify "BATT LOW VOLTAGE"
condition)
0 - 600 sec 10 sec
“LV CUT OFF TIME”
(Time in "BATT LOW VOLTAGE"
condition to trigger complete
shutdown)
0 - 7200 sec 1200 sec
“EQUALIZE-4STAGES”
(4 Stage Adaptive Equalization On/ Off)
0 = No (3-Stage / 2-Stage)
1 = Yes (4-Stage Equalization)
0 = No (3-Stage / 2-Stage)
"MODE" 0 = Normal…AC input priority (Off-Line)
1 = On-Line…Inverter priority
2 = Charger Only…Charging & AC bypass
only,
no inverting
0 = Normal
"ONLINE OPTION" 0 = Option 1
1 = Option 2
0 = Option 1
"RESET TO BULK" 10.00V to 13.00V 20.00V to 26.00V 12.00V 24.00V
"GS DETECT TIME" 0 - 600 sec 10 sec
"GEN ON TIME" 0 - 240 min 60 min
"GEN OFF DELAY" 0 - 240 min 60 min
"ABSORP TIME" 0 - 600 min 60 min
"ABSORP EXIT AMPS" 0 - 20A 4A
"CHARGING PROFILE" 0 = 3 Stage Adaptive
1 = 3 Stage Type 1
2 = 3 Stage Type 2
3 = 2 Stage Type 1
4 = 2 Stage Type 2
5 = 2 Stage Type 3
0 = 3 Stage Adaptive
"BATTERY TYPE" 0 = Lead Acid
1 = Lithium
0 = Lead Acid
"SAFE CHARGING" 0 - 300 min 0 min
NOTE 1:
"BULK CURRENT" value may automatically reduce in higher ambient temperatures of around 50° - 60°C if Power
Transformer temperature exceeds 130°C or Heat Sink temperature exceeds 65°C. (See Section 4.9.3)
