SAMLEX AMERICA INC. | 123
SECTION 6 | Operation, Protections and Troubleshooting
TABLE 6.3 PROGRAMMABLE AND DEFAULT PARAMETERS: PARAMETER GROUP NO.2 "INPUT SETTING"
Group Parameter name
Programming Range Default value
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
INPUT
SETTING
DEFAULT FREQ 0 = 60Hz* 0 = 60Hz*
GRID MAX
CURRENT
5 - 20A 20A
HIGH CUT OFF 50 – 70Hz 65Hz
HIGH RESET 50 – 70Hz 64Hz
LOW CUT OFF 40 – 60Hz 55Hz
LOW RESET 40 – 60Hz 56Hz
SYNCHRONIZATION 0 = Fine ; 1 = Coarse 0 = Fine
INPUT OC PROTECT 0 = INV Mode ; 1 = Shutdown 0 = INV Mode
INPUT RECOVERY 0 = Buffered ; 1 = Direct 0 = Buffered
* Fixed at 60 Hz. Changing to other option 0 (say 1 ), will show "!1=xxHz" meaning option 1 is invalid
TABLE 6.4 PROGRAMMABLE AND DEFAULT PARAMETERS: PARAMETER GROUP NO.3 "INPUT LOW LIMIT"
Group Parameter name
Setting range Default value
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
INPUT -
LOW LIMIT
RESET VOLTAGE 60.0 – 120.0V 105.0V
CUT OFF VOLT 1 60.0 – 120.0V 100.0V
DETECT TIME 1 0 – 2000 cycle 300 cycle
CUT OFF VOLT 2 60.0 – 120.0V 95.0V
DETECT TIME 2 0 – 2000 cycle 60 cycle
CUT OFF VOLT 3 60.0 – 120.0V 90.0V
DETECT TIME 3 0 – 2000 cycle 1 cycle
