SECTION 6 | Operation, Protections and Troubleshooting
TABLE 6.5 PROGRAMMABLE AND DEFAULT PARAMETERS: PARAMETER GROUP NO.4 "INPUT HIGH LIMIT"
Group Parameter name
Setting range Default value
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
INPUT -
HIGH LIMIT
RESET VOLTAGE 120.0 – 150.0V 125.0V
CUT OFF VOLT 1 120.0 – 150.0V 135.0V
DETECT TIME 1 0 – 2000 cycle 60 cycle
CUT OFF VOLT 2 120.0 – 150.0V 140.0V
DETECT TIME 2 0 – 2000 cycle 15 cycle
CUT OFF VOLT 3 120.0 – 150.0V 145.0V
DETECT TIME 3 0 – 2000 cycle 1 cycle
TABLE 6.6 PROGRAMMABLE AND DEFAULT PARAMETERS: PARAMETER GROUP NO.5 "OTHER FUNCTIONS"
Parameter name
Setting range Default Value
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
“POWER SAVING” 1 = Enable 0 = Disable 0 = Disable
“ENTER POINT” 4 – 50W 6W
“WAKE UP POINT” 5 – 50W 7W
“REMOTE SWITCH”
For ON /OFF control
through external 12V
signal fed to Remote
ON / OFF terminals on
the Front Panel (15,
Fig 2.1)
0 = Button Type: 12V signal is fed through Push Button
Type of Switch
Pressing of Push Button > 2 sec will switch the unit
ON
When ON, pressing Push Button > 5 sec will turn the
unit OFF
1 = Switch Type: 12V signal is fed through contacts of
Toggle Type of Switch or relay contact
ON condition (contacts closed) will turn the unit ON
OFF condition (contacts open) for 2 sec will switch
the unit OFF
0 = Button Type
CAUTION! ON/OFF Logic also
controls the operation of the ON/
OFF Button on the front panel
(11, Fig 2.1). The Default setting is
"Button Type".
If the ON/OFF Control is changed
to external "Remote Switch", it will
not be possible to switch ON/OFF
the EVO Inverter/Charger from the
front panel ON/OFF Push Button
because it will work with Switch
Type Logic. It will be ON only as
long as the Push Buttom is kept
pressed and will switch OFF when
released.
Table continues on next page }
