Samlexpower Evolution Series - Page 125

SAMLEX AMERICA INC. | 125
SECTION 6 | Operation, Protections and Troubleshooting
TABLE 6.6 PROGRAMMABLE AND DEFAULT PARAMETERS: PARAMETER GROUP NO.5 "OTHER FUNCTIONS"
(Continued)
Parameter name
Setting range Default Value
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
EVO-1212F
EVO-1212F-HW
EVO-1224F
EVO-1224F-HW
“RELAY FUNCTION”
(for Status Relay)
0 = Charge / Other
 OFF in "Charging" Mode
 ON in other Modes i.e. "Inverting", "Power Saving" or
"Standby"
1 = Normal / Fault
 OFF in normal operating conditions
 ON in Fault Modes
2 = Generator 0
 ON when batteries drop to "LOW VOLT ALARM" or lower
for period = "GS DETECT TIME" - Initiates Generator start
 OFF after batteries are charged till the end point of the
programmed option under parameter "CHARGING
PROFILE"[See Section 4.8.2.5.2.1 of EVO-RC-PLUS Remote Control
Manual]. When the relay switches OFF, it initiates Generator
Stop.
3 = Generator 1
 ON when batteries drop to "LOW VOLT ALARM" or lower
for period = "GS DETECT TIME" - initiates Generator start
 OFF when batteries are charged to "RESET VOLTAGE" for
period = "GEN OFF TIME" - initiates Generator stop
4 = Generator 2
 ON when batteries drop to "LOW VOLT ALARM" or lower
for period = "GS DETECT TIME" - initiates Generator start
 OFF after period = "GEN ON TIME" from the time relay
switched ON - initiates Generator stop
2 = Generator 0
“COMM ID”
(Communication ID for
optional Remote Control
EVO-RC-PLUS)
1 - 255 1
“BUZZER” 0 = OFF ; 1 = ON 1 = On
“DISCHARGE BEEP”
(Beeping in “Discharg-
ing / Inverter Mode”)
0 = OFF ; 1 = ON 0 = Off
“DEFAULT RESET” 0 = No ; 1 = YES 0 = No
DATA LOG TIME
(For Optional Remote
Control EVO-RC-PLUS)
0 = Disable 3 = 30 sec 6 = 10 min
1 = 1 sec 4 = 1 min 1
2 = 10 sec 5 = 5 min 1
1 = 1 sec
PARAMETER SAVE
(For Optional Remote
Control EVO-RC-PLUS)
0 = No
1 = Yes
0 = No
TEMP UNIT
0 = C
1 = F
0 = C
PASSWORD DISABLE 0 = No
1 = Yes
0 = No
