4 | SAMLEX AMERICA INC.
4. CAUTION! For indoors use only.
5. WARNING! Hot Surfaces! To prevent burns, do not touch!
6. CAUTION! The AC input / output wiring terminals are intended for eld connection using Copper conductors
that are to be sized based on 75°C. See Table 1.1.1 for sizing of conductors for AC INPUT circuits and Table
1.1.2 for sizing of conductors for AC OUTPUT circuits.
7. WARNING! Over current protection (AC Breakers) for the AC input / output circuits has NOT been provided
for EVO-1212F-HW and EVO-1224F-HW and has to be provided by the installer / user. See guidelines at Table
1.1.1 for sizing of breakers for AC INPUT circuits and Table 1.1.2 for sizing of breakers for AC OUTPUT circuits.
National and Local Electrical Codes will supersede these guidelines.
8. CAUTION! The battery terminals are intended for eld connection of battery side cables using Copper
conductors that are sized based on 90°C. See Table 1.1.3 for recommended sizes of battery side cables for
installation in free air and conduit respectively.
9. WARNING! Over current protection (fuse) for battery and External Charger circuits has NOT been provided and
has to provided by the installer / user. See guidelines at Table 1.1.3 for recommended sizes for installation in free
air and conduit respectively. National and Local Electrical Codes will supersede these guidelines.
10. Tightening torques to be applied to the wiring terminals are given in Table 1.1.4.
11. This unit has been provided with integral protections against overloads.
12. WARNING! To reduce risk of electric shock and re:
 Installation should be carried out by certied installer and as per Local and National Electrical Codes.
 Do not connect to circuit operating at more than 150 Volts to Ground.
 Do not connect to AC Load Center (Circuit Breaker Panel) having Multi-wire Branch Circuits connected .
 Both AC and DC voltage sources are terminated inside this equipment. Each circuit must be individually
disconnected before servicing.
 Do not remove cover. No user serviceable part inside. Refer servicing to qualied servicing personnel.
 Do not mount in zero clearance compartment.
 Do not cover or obstruct ventilation openings.
 Fuse(s) should be replaced with the same type and rating as of the original installed fuse(s).
13. WARNING! Risk of electric shock. Use only those GFCIs that are listed at Table 1.1.5. Other types may fail to
operate properly when connected to this unit.
14. GROUNDING: The Grounding symbol shown below is used for identifying only the eld wiring equipment-
grounding terminal. However, this symbol is usable with the circle omitted for identifying various points within
the unit that are bonded to Ground.
Grounding Symbol / Défaut à la terre
15. WARNING! Precautions When Working With Batteries.
Lead Acid Batteries
 Batteries contain very corrosive diluted Sulphuric Acid as electrolyte. Precautions should be taken to prevent
contact with skin, eyes or clothing. Wear eye protection.
 Batteries generate Hydrogen and Oxygen during charging resulting in evolution of explosive gas mixture.
Care should be taken to ventilate the battery area and follow the battery manufacturer’s recommendations.
SECTION 1.1 | Safety Instructions
