Design and principle of operation
Table5: Attachment to NAMUR rib or attachment to rod-type yokes according to
IEC60534-6 (section5.3)
Order no.
5 to 50mm travel, lever already on positioner
For actuators
1402-0330
Actuators from other manufacturers and Type3271 with 120 to 700 cm² effective
areas
Accessories
Connecting plate
G¼ 1402-0235
¼ NPT 1402-0236
Pressure gauge bracket
G¼ 1402-0237
¼ NPT 1402-0238
Pressure gauge mounting kit up to max. 6bar
(output/supply)
Stainless steel/brass 1400-6950
Stainless steel/st.steel 1400-6951
Table6: Attachment to rotary actuators (section 5.5)
Order no.
Light version
VDI/VDE3845 (September 2010), level 1
1)
, AA1 size 1402-0243
VDI/VDE3845 (September 2010), level 2
1),
AA2 size 1402-0244
VETEC TypeS160 Actuator or SAMSON Type 3278 Rotary Actuator (160cm²) 1402-0294
VETEC Type S320 1402-0295
Heavy-duty version
VDI/VDE3845 (September 2010), level 1
1)
, AA1 to AA4 size 1402-1097
VDI/VDE3845 (September 2010), level 2
1)
1402-1099
VETEC Type S160/R 1402-1098
Accessories
Connecting plate
G¼ 1402-0235
¼ NPT 1402-0236
Pressure gauge bracket
G¼ 1402-0237
¼ NPT 1402-0238
Pressure gauge mounting kit up to max. 6bar
(output/supply)
Stainless steel/brass 1400-6950
Stainless steel/st. steel 1400-6951
Connecting plate for Type3710 Reversing Amplier 1402-0512
1)
See page24 for details.
