Code
no.
Parameter – Display, values
[default setting]
Description
Note: Codes with marked with an asterisk (*) must be enabled with Code 3 prior to configuration.
40
Minimum transit time OPEN
0 to 240 s [0 s]
Time [s] needed by the system (positioner, actuator and valve) to
move through the nominal travel/angle to open the valve (100 %
position).
Display only
41
Minimum transit time
CLOSED
0 to 240 s [0 s]
Time [s] needed by the system (positioner, actuator and valve) to
move through the nominal travel/angle to close the valve (0 %
position).
Display only
42
Auto-w/manual-w
0.0 to 100.0 % of the span
4 to 20 mA
Supplied manual and automatic reference variable
Display only
43
Firmware version control
Xxxx
Positioner type and current firmware version (in alternating se-
quence)
Display only
44
y info
0 to 100 %, [0 %]
Control signal y [%] based on the travel range determined on ini-
tialization · Display only
MAX: The positioner builds up its maximum output pressure,
see description in Code 14 and 15.
0 P: The positioner vents completely, see description in
Code 14 and 15.
– – –: The positioner has not been initialized.
45
Forced venting status
No · HIGH/LOW · YES
Indicates whether the option is installed or not · Display only
No No forced venting installed
YES Forced venting installed
If a voltage supply is connected at the terminals of the optional
forced venting,
YES and HIGH appear on the display in alter
-
nating sequence. If a voltage supply is not applied (actuator
vented, fail-safe position indicated on the display by the
S icon),
YES and LOW appear on the display in alternating sequence.
46*
Polling address
0 to 15/63 [0]
ESC
Select bus address
0 to 15 for active HART
®
Revision 5 (default setting)
0 to 63 for active HART
®
Revision 6.
The address can only be switched over using the operating
software.
74 EB 8387-3 EN
Code list
