Samson 5857 - Communication

EB 5857 EN 3-3
Design and principle of operation
3.1.1 Communication
Serial interface
Theactuatorwithpositioneristtedwithan
RS-232 serial interface. This allows commu-
nication with TROVIS-VIEW using SSP proto-
col(seeFig.3-2).
Serial interface
Fig.3-2: Serial interface
Conguration
Theactuatorwithpositioneriscongured
with the TROVIS-VIEW software. In this case,
the serial interface on the actuator is used to
connect the actuator to the computer. The
TROVIS-VIEW software enables the user to
easilycongurethepositioneraswellas
view process parameters online.
TROVIS-VIEW can be downloaded free of
charge from our website at
uwww.samsongroup.com > Service &
Support > Downloads > TROVIS-VIEW.
Further information on TROVIS-VIEW (e.g.
system requirements) is available on our
website and in the Data Sheet uT6661 as
well as the Operating Instructions
uEB6661.
Î Seethe'Start-upandconguration'sec-
tion.
Note
