Samson 5857 - Copying Function; Data Logging

8-8 EB 5857 EN
Operation
8.4.1 Copying function
ThememorypencanbeusedtocopysettingdatatootherTypes5857Actuatorsafterthe
data from the actuator have been transferred to the memory pen.
'Automatically write to memory pen' is automatically reset to the read status after data are
transferred from the actuator for the rst time.
8.4.2 Data logging
The memory pen-64 allows the following data to be saved:
− Inputin%
− Actuatortravelin%
− Positionfeedbackin%
− Temperatureinsidedevicein°C
− Torque switch: Actuator stem retracted
− Torque switch: Actuator stem extended
− Position feedback is relative
− Malfunctions
− Input signal failure
− Direction of action switch
− Initialization key
The data are logged until the memory capacity of the memory pen is full.
DatainthememorypencanbesavedtoadataloggingleusingtheTROVIS-VIEWsoft-
ware.
Data logging
Î Seesection8.4fortheblinkingpattern.
1. Plugthememorypenintotheserialinterfaceoftheactuator(Fig.8-3).
The yellow LED on the actuator indicates that the data logging is being prepared.
A change in the blinking pattern of the yellow LED indicates that data are being saved to
the memory pen.
Note
