Samson 5857 - Idle Time During End Position Guiding; Velocity

EB 5857 EN 16-7
Annex A (conguration instructions)
16.5.3 Idle time during end position guiding
In closed-loop operation, the actuator's positioner must be operated with absolute travel ad-
justment (default setting).
Change the travel adjustment in the 'Settings' folder (Actuator\Travel).
Settings\Actuator\Functions
Function WE Adjustment range
Idle time during end position guiding 0s 0 to 99 s
The further description refers to the operation with absolute travel adjustment, unless speci-
ed otherwise.
16.5.4 Velocity
The actuator stem moves to the position determined by the input signal at the selected strok-
ing speed. There are three speed levels:
− Slow = 0.2mm/s
− Standard = 0.3mm/s
− Fast = 0.55mm/s
Settings\Actuator\Travel
Function WE Adjustment range
Velocity Standard Slow, Standard, Fast
The transit time is calculated from the travel and the stroking speed. The transit time is the
time that the actuator stem needs to move through the adjusted travel.
The following applies: Transit time in s
=
Travel in mm
Stroking speed in mm/s
Note
Note
