Samson 5857 - Configuration List and Customer-Specific Data

EB 5857 EN 17-3
Annex B
17.3 Conguration list and customer-specic data
Conguration Default setting Adjustment range Setting
Input signal
Lower range value 0.0V 0.0to7.5V
Upper range value 10.0V 2.5to10.0V
Position feedback signal
Lower range value 0.0V 0.0to10.0V
Upper range value 10.0V 0.0to10.0V
Functions
Detect input signal failure No Yes/No
Positioning value upon input signal
failure
Internal Internal/last position
Internal positioning value 0.0% 0.0to100.0%
End position guiding when the value
falls below the limit
1.0% 0.0to49.9%
Value below limit (end position guid-
ing)
97.0% 50.0to100.0%
Blockage detection No Yes/No
Blockage removal No Yes/No
Indicate blockage No Yes/No
Blocking protection No Yes/No
Limited travel range 100.0% 30.0to130.0%
Travel adjustment Absolute Absolute/Relative
Velocity Standard Slow/Standard/Fast
Dead band (switching range) 2.0% 0.5to5.0%
Characteristic type Linear
Linear
Equal percentage
Reverse equal percent-
age
User-dened
