Samson 5857 - Annex A: Dead Band and Characteristic

16-8 EB 5857 EN
Annex A (conguration instructions)
16.5.5 Dead band (switching range)
The dead band determines how sensitive the actuator reacts. A change in the input signal by
thehysteresisrstcausesaminimallysmallchangeinthevalveposition.
Settings\Actuator\Travel
Function WE Adjustment range
Dead band (switching range) 2.0% 0.5to5.0%
16.5.6 Characteristic
The characteristic expresses the relation between the input signal and the actuator stem posi-
tion.
Perform the characteristic settings in the Settings folder (Actuator\Characteristic):
