Parameters Adjustment
range
WE Comments
Klappenlaufzeit
(shut-off valve transit
time)
0 to 300 min 3 min Time waited until circulation pump activated
Control parameters
Kp 0.1 to 99.9 1.0 Gain factor of heat exchanger control circuit
Tn 0 to 999 s 30 s Reset time of heat exchanger control circuit
Tv 0 to 999 s 0 s Derivative-action time of heat exchanger control cir
-
cuit
Ty 15 to 600 s 45 s Valve transit time of heat exchanger control circuit
EB 5571-2 EN 75
Appendix
