INSTALLATION
FCU KIT power cable specication
This specication is when installing a FCU KIT.
Europe
Power supply Power cable Ground wire Communication cable ELCB
AC 220 - 240 V~ 50 Hz, 1 Ph
Min. 2.5 mm
2
(0.0039 inch
2
)
Min. 2.5 mm
2
(0.0039 inch
2
)
Min. 0.75 mm
2
(0.0012 inch
2
)
15 A
Part Rated Capacity
Fan (High, Mid, Low) AC 220 - 240 V~ 50 Hz, 1 Ph, 1 A
Water Valve AC 220 - 240 V~ 50 Hz, 1 Ph, 0.5 A
USA
Power supply MCA MOP
AC 208 - 230 V~ 60 Hz, 1 Ph 2.75 15 A
Part Rated Capacity
Fan (High, Mid, Low) AC 208 - 230 V~ 60 Hz, 1 Ph, 1 A
Water Valve AC 208 - 230 V~ 60 Hz, 1 Ph, 0.5 A
DC Wire
Part Rated Capacity
Remote controller DC 12 V
External contact Zero voltage contact input
Sensor cable NTC ./10 kΩ 25 °C

y
Purpose of control: Operating control

y
Construction of control: Independently mounted control

y
Rated impulse voltage: 2500 V
FCU KIT installation
