Samsung DVM - Setting FCU KIT installation option

35
SETTING
CAUTION
• Main address (SEG5 ~ SEG6) can be set in range of 0 ~ 47.
• When using automatic address setting, FCU interface module automatically assigns
FCU KIT address between 00 ~ 15.
• If you set the SEG 3 as 0, the FCU KIT will maintain the existing main address even if
you input the option value of SEG5 ~ SEG6.
• If you set the SEG9 as 0, the FCU KIT will maintain existing RMC address even if you
input the option value of SEG11 ~ SEG12.
Setting FCU KIT installation option
1 Check if power is supplied to FCU KIT.

y
When the power is not supplied to FCU KIT, there should be additional power supply to
it.
2 Remote controller receiver of wireless remote controller is included in FCU KIT PBA.
3 Depending on the installation condition of FCU KIT, installation option to each FCU KIT
should be set.
4 Set the FCU KIT installation option by using a remote controller.

y
The default setting value of the FCU KIT installation option is "020010-100000-200000-
300000".
