3.DisassemblyandReassembly
DescriptionDescriptionPhoto
6.ToremovetheMAIN+AMPASSY ,PCBunfasten5screwsonthe
boardand2ontherear.
:BH,+,-,B,M3,L6,ZPC(WHT),SWRCH18A,RF
Removethebridgeconnectionbetweenthemainandpower,
removethefancableconnectionandremovethemetalsupport
postinthecenter.
RemovetheMAINfromthecase.
7.UnplugtheFANcableconnectedtothemainboardandthen
removethemainboardfromthecase.
8.BeforepullouttheSMPSPCB,Unplugtheconnector.
9.ForSMPS,PCBunfasten4screwsonbottom-side.
:BH,+,-,B,M3,L6,ZPC(WHT),SWRCH18A,RF
