English - 124
The following table shows the approximate time in seconds to switch from the TV to the input source, based
on the priority.
Scenario 1: When no inputs are connected.
Source To Connect
AV 2 Sec
PC 0.7 Sec
HDMI 3.9 Sec
Scenario 2: When two or more inputs are connected and an Input source is disconnected and then reconnected.
Source Disconnect To Connect Total
AV 4.5 Sec 2 Sec 6.5 Sec
PC 0.7 Sec 0.7 Sec 1.4 Sec
HDMI 3.9 Sec 3.9 Sec 7.8 Sec
E.g. If the RJP has all its live sources (AV, PC and HDMI) connected, AV is viewed as the highest priority. If the RJP
is in HDMI mode, and a guest removes and reconnects the AV, the minimum time required to switch to the AV is 6.5
seconds.
To connect audio (Ipod or Mp), Music mode should be ON and Jack Ident detect should be OFF.
A/V, PC and HDMI input sources are supported.
➣
➣
➣
