7
CableCARD™
Insert a CableCARD into the slot. (Refer to page 69)
8
WISELINK
Connect a USB mass storage device to view photo les and play audio les.
9
AV IN 2
Video and audio inputs for external devices, such as a camcorder or VCR.
S-VIDEO
Connects an S-Video signal from a camcorder or VCR.
0
(HEADPHONE)
Connects a set of external headphones for private listening.
!
*RJP
Connect this to the jack on the optional RJP(Remote Jack Pack). This will allow you to conveniently connect external
devices(Camcoder, PC, DVD players etc).
@
POWER INPUT
Connects the supplied power cord.
#
*VOL-CTRL
Used to control the volume of the Bathroom speaker. Connect the Bathroom Wall Box and the VOL-CTRL port.
$
AUDIO OUT [R-AUDIO-L]
Connect RCA audio cables to AUDIO OUT [R-AUDIO-L] on the rear of your set and the other ends to corresponding
audio in connectors on your Amplier or DVD Home Theatre.
*VARIABLE [R-AUDIO-L]
Used for the audio output to the Bathroom speaker. Connect the Bathroom Wall Box and the Variable port (RCA).
%
COMPONENT IN 1, 2 / AV IN 1
Connects Component video/audio.
The COMPONENT IN 1 jack is also used as the AV IN 1 jack.
- Connect the video cable to the COMPONENT IN 1 [Y/VIDEO] jack and the audio cable to the COMPONENT IN 1
[R-AUDIO-L] jacks.
^
EX-LINK
Connect this to the jack on the optional wall mount bracket. This will allow you to adjust the TV viewing angle using your
remote control.
&
KENSINGTON LOCK
The Kensington Lock (optional) is a device used to physically x the system when used in a public place. If you want to
use a locking device, contact the dealer where you purchased the TV.
The location of the Kensington Lock may be different depending on your model of TV.
*These items are for use in commercial hotel installations only.
➣
