Samsung NX10 Service Manual

Contents
1. Product Specification
1-1 Specifications . .................................................................................... 1-1
1-2 Instructions on how to use the memory card . ............................... 1-4
1-3 LCD monitor indicator . ...................................................................... 1-5
1-4 Camera connections diagram ........................................................... 1-6
1-5 Identification of features .................................................................... 1-7
2. Operation Instruction & Installation
2-1 Install .................................................................................................... 2-1
2-2 FAQ ...................................................................................................... 2-5
3. Exploded View and Parts List
3-1 Total assembly ..................................................................................... 3-1
3-2 Body assembly. ................................................................................... 3-2
3-3 Main assembly . .................................................................................. 3-4
3-4 Mount holder assembly ..................................................................... 3-6
3-5 Viewfinder assembly . ........................................................................ 3-9
3-6 Front cover assembly . ......................................................................3-11
3-7 Back cover assembly . ..................................................................... 3-12
3-8 Top cover assembly . ........................................................................ 3-14
3-9 Package items ..................................................................................... 3-17
4. Firmware update
4-1 F/W upgrade of Body by using user menu ..................................... 4-1
4-2 Upgrading procedure by using C/S menu. ..................................... 4-2
5. Adjustment
5-1 Basic guide for adjustment ............................................................... 5-1
5-2 Tester Mode......................................................................................... 5-2
5-3 CIS TILT Adjustment .......................................................................... 5-3
5-4 Input CIS DOT & Adjust the Shutter Speed (ADJ_01) ................. 5-4

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
