Samsung NX10 Service Manual

Product Specication
SAMSUNG This Document can not be used without Samsung's authorization 1-1
1. Product Specification
1-1 Specifications
Specifi cation NX10
Sensor
Type CMOS
Sensor size 23.4×15.6mm
Effective Pixel Approx. 14.6 Mega-pixels
Total Pixel Approx. 15.1 Mega-pixels
Color Filter RGB primary color fi lter
Lens Mount Samsung NX Mount
Usable Lens Samsung Lenses
Stabilization
Type Lens Shift (depends on
Lens)
Dust
Reduction
Type Super sonic drive
Display Type AMOLED
Size 3.0”
Resolution VGA (640x480) 614k dots
(PenTile).
Live view Field of view : Approx. 100%
Viewfi nder Type EVF
Resolution VGA (640x480) 921k dots
equiv.
Field of View Approx. 100%
Magnifi cation Approx. 0.86x (APS-C,
50mm, -1m
-1
)
Eyepoint About 20.2mm
Diopter
Adjustment
Approx. -4.0 ~ +2.0m
-1
Specifi cation NX10
Focusing Type Contrast AF
Focusing point Selection : 1point (Free
selection)
Multi : Normal 15points,
Close Up 35points
Face Detection : Max.
10faces
Modes Single AF, Continuous AF,
MF
AF-assist lamp Yes (Green LED)
Shutter Type Electronically controlled
vertical-run focal plane
shutter
Speed Auto:1/4000sec. ~ 30sec.
Manual:1/4000sec. ~
30sec. (1/3EV or 1/2EV
step)
Bulb (Limit time : 8 min)
Exposure Metering
System
TTL 247 (19x13) Block
segment
Metering : Multi, Center-
weighted, Spot
Metering range : EV0 ~ 18
(ISO100·30mm F2.0)
Compensation ±3 EV (1/2EV, 1/3EV step)
AE Lock AEL button
ISO Equivalent Auto, 100, 200, 400, 800,
1600, 3200 (1EV step)

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
