Samsung NX10 Service Manual

Product Specication
1-2 This Document can not be used without Samsung's authorization SAMSUNG
Specifi cation NX10
Drive Mode Modes Single, Continuous, Burst,
Self-timer, Bracket (AE, WB,
PW)
Continuous JPEG : 3fps up to 10shots,
Burst mode : 30fps, 30shots
by 1 released
RAW : 3fps up to 3shots
Bracket Auto Exposure Bracket
(±3EV), White Balance
Bracket (±3step), Picture
Wizard Bracket (Selectable
3modes)
Self-timer 2-30sec. (1sec. step)
Remote
controller
Wired : SR9NX01 (Optional)
Specifi cation NX10
Flash Type TTL Auto Pop-up fl ash
Modes Smart Flash, Auto, Auto +
Red-eye reduction, Fill-in,
Fill-in + Red-eye reduction,
1
st
Curtain, 2
nd
Curtain, OFF
Guide Number 11 (at ISO 100)
Angle of View
Coverage
28mm wide-angle
(Equivalent to 35mm)
Sync. Speed Less than 1/180sec.
Flash
Compensation
-2 - +2EV (0.5EV step)
External Flash Samsung External Flash
available (SEF42A, SEF20A)
(optional)
Synchro
(Flash
attachment)
Hot Shoe
White
Balance
Modes Auto, Daylight, Cloudy,
Fluorescent (W, N, D),
Tungsten, Flash, Custom,
K(Manual)
Micro
adjustment
Each 7steps in Amber / Blue
/ Green / Magenta axis
Wizard
Modes Standard, Vivid, Portrait,
Landscape, Forest, Retro,
Cool, Calm, Classic,
Custom (1-3)
Parameter Contrast, Sharpness,
Saturation, Color tone

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
