Samsung NX10 Service Manual

Product Specication
SAMSUNG This Document can not be used without Samsung's authorization 1-3
Specification NX10
Shooting Modes Smart Auto, Program,
Shutter Priority AE, Aperture
Priority AE, Manual, Night,
Portrait, Landscape, Scene,
Movie
Scene Mode Beauty shot, Children, Close
Up, Text, Sunset, Dawn,
Backlight, Fireworks, Beach
& Snow
Image Size JPEG (3:2):
14M (4592x3056),
10M (3872x2592),
6M (3008x2000),
2M (1920x1280),
1.4M (1472x976):
Burst mode only
JPEG (16:9):
12M (4592x2584),
8M (3872x2176),
5M (3008x1688),
2M (1920x1080)
RAW: 14M (4592x3056)
Quality Super fine , Fine, Normal
RAW Format SRW
Color Space sRGB, Adobe RGB
Specification NX10
Movie Format MP4 (H.264)
Compression Movie : H.264 , Sound :
AAC
Movie Clip With Audio or without Audio
(user selectable, recording
time : 25 minutes)
Image size 1280x720 , 640x480 ,
320x240
Frame rate 30fps
Sound Mono Sound
Movie Editing Still Image Capture, Time
Trim ming
Image Play Type Single image, Thumbnails
(3/9/20 images), Slide show,
Movie
Highlight
Warning
Available
Editing Red eye fix, Back light comp.,
Photo Style Selector, Resize,
Rotate, Face Retouch
Photo Style
Selector
Soft, Vivid, Forest, Autumn,
Misty, Gloomy, Classic
118
Specification NX10
Storage Media SD, SDHC
File Format RAW (SRW), JPEG (EXIF
2.21), DCF, DPOF 1.1,
PictBridge 1.0
Capacity
(1GB)
14M : RAW 35
14M : Super Fine 142, Fine
278, Normal 408
10M : Super Fine 197, Fine
382, Normal 724
6M : Super Fine 322, Fine
615, Normal 1128
2M : Super Fine 738, Fine
1334, Normal 2238
Burst (1.4M) : Super Fine
1490, Fine 2301, Normal
2971
12M(W) : Super Fine 168,
Fine 328, Normal 630
8M(W) : Super Fine 234,
Fine 454, Normal 860
5M(W) : Super Fine 381,
Fine 727, Normal 1334
2M(W) : Super Fine 872,
Fine 1573, Normal 2638
Movie : 1280x720 : High
Quality 15min., Normal
22min.
640x480 : High Quality
44min., Normal 66min.
320x240 : High Quality
145min., Normal 210min.
※ These figures are
measured under the
Samsung standard
Direct Printing PictBridge
Specification NX10
Interface Digital Output
Connector
USB 2.0 (HI-SPEED)
Video output NTSC, PAL (user selectable)
HDMI 1.3 : (1080i, 720P,
576P / 480P)
External
Release
Yes
DC power input
connector
DC 9.0V, 1.5A (100 ~ 240V)
Power
Source
Type
Rechargeable battery :
BP1310 (1300mAh)
Charger: BC1310
AC Adaptor : AD9NX01
(Optional)
* Included battery may vary
depending on sales region
Physical
Specification
Dimensions
(WxHxD)
123×87×39.8mm (excluding
the projecting parts of the
camera)
Weight
353g (without batteries and
card)
Operating
Temp eratu re
0 ~ 40 °C
Operating
Humidity
5 ~ 85%
Software
Application
Samsung Master, Samsung
RAW Converter, QuickTime
Player 7.6
* Specifications are subject to change without prior notice
* All trademarks are the property of their respective owners

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
