Adjustment
5-10 This Document can not be used without Samsung's authorization SAMSUNG
5-10 Proximity Sensor Adjustment (ADJ_08)
<How to adjust>
1.Changethesettingonthetestermodeasbelow.
 -TESTMODE:Left→OK→Right→Ev+OKbuttonatthesametime.
- 3. Select ADJUSTMENT CONTROL.
- (2) LINE PROCESS STEP value is 08.
- (3) LINE PROCESS MARK value is 07.
2.InserttheSDcardtothecamerawhichcontainedadjustmentdata.
3.Thedistancebetweeneyepiecelensandcamerais4.5cm
4.Afterturningonthecamera,itwillbestartautomatically.
5.Afterturningonthecamera,itwillbestartautomatically.
<Adjustment Result>
YoucanseetheadjustmentresultbyusingLogFilesavedonthememorycard.Youcanalsoconrmthe
ADJUSTMENTRESULTontheTestermode.
■ To adjust the distance of EVF perceive sensor.
Fig. 5-4
wall
4.5Cm
Camera
Tripod
