Samsung NX10 Service Manual

SAMSUNG This Document can not be used without Samsung’s authorization 3-3
Exploded View and Parts List
Loc. No Parts No.. Description Q ty Available Remark
2-1 AD63-04551A SHEET-THERMAL PAD A 1 X
2-2 AD63-04552A SHEET-THERMAL PAD B 2 X
2-3 AD61-04094A HOLDER-LCD 1 O
2-4 AD63-04464A T/SHEET LCD HOLDER 2 X
2-5 AD63-04955A T/SHEET LCD HOLDER B 4 X
2-6 6003-001692 SCREW-TAPTYPE 3 X
2-7 6001-002316 SCREW-MACHINE 1 X
2-8 AD63-04454A CUSHION LCD CONNECTOR 1 X
2-9
AD97-17738A COVER ASSY-JACK 1 O BLACK
AD97-17738B COVER ASSY-JACK 1 O TITTAN SILVER
2-10 AD97-17739A ASSY-HOLDER EP CAP 1 O
2-11 6003-001704 SCREW-TAPTYPE 5 X
2-12 6001-002162 SCREW-MACHINE 1 X
2-13 6001-002278 SCREW-MACHINE 2 X
2-14 6003-001705 SCREW-TAPTYPE 1 X
2-15 AD61-04069A BASE EP CAP 1 X
2-16 AD73-00330A RUBBER EP CAP 1 X
2-17 AD61-04096A PLATE-SPRING SHOE 1 O
2-18 AD63-03979A GRIP-BACK 1 O
2-19 AD64-02655A WINDOW-LCD 1 O
2-20 6003-001637 SCREW-TAPTYPE 1 O
2-21 AD63-03978A SIDE GRIP 1 O
2-22 AD97-17740A ASSY-RUBBER EP CAP_BLACK 1 O
2-23
AD63-03958A COVER BATTERY 1 X BLACK
AD63-03958B COVER BATTERY 1 X TITTAN SILVER
2-24 AD66-00685A SHAFT BATTERY COVER 1 O
2-25 6107-001774 SPRING BATTERY COVER 1 O
2-26 AD66-00668A LEVER BATTERY COVER LOCK 1 X
2-27 AD61-04082A PLATE BATTERY COVER 1 X
2-28
AD97-17794A ASSY-BATTERY COVER COVER 1 O BLACK
AD97-17794B ASSY-BATTERY COVER COVER 1 O TITTAN SILVER
2-29 AD07-00117A OLED AM 1 O

Samsung NX10 Specifications

General

Megapixel	14.6 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Maximum image resolution	4592 x 3056 pixels
Still image resolution(s)	1472 x 976, 1920 x 1080, 1920 x 1280, 3008 x 1688, 3008 x 2000, 3872 x 2176, 3872 x 2592, 4592 x 2584
Digital zoom	- x
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Focus adjustment	Auto
Auto focusing (AF) modes	Multi Point Auto Focus
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Video formats supported	H.264, MP4
Maximum video resolution	1280 x 720 pixels
Display diagonal	3 \
Display resolution (numeric)	614000 pixels
USB version	2.0
Product color	Black
Battery type	BP1310
Battery capacity	1300 mAh
Battery life (max)	3.5 h
Battery life (CIPA standard)	400 shots
Bundled software	SAMSUNG Master, SAMSUNG RAW Converter 3.1 Adobe Reader, QuickTime Player 7.6
Operating temperature (T-T)	5 - 85 °C
Maximum operating temperature range (T-T)	0 - 40 °C
Flash modes	fill-in, Red-eye reduction, second curtain synchro
Scene modes	Documents, Night, Portrait, Landscape (scenery)
Camera playback	single image, slide show

Weight and Dimensions

Depth	87 mm
Width	123 mm
Height	39.8 mm
Weight	353 g
